Thông Số Kỹ Thuật
| Channels (Mono + Stereo) | 18 + 4 |
| Auxiliarys (MON, FX, AUX) | 2 Pre, 2 Post, 2 Pre/Post switchable |
| MIC GAIN (Mono / Stereo) | 0 to +60 dB / +10 to +60 dB |
| LINE/CD/USB GAIN (Stereo) | -10 to +20 dB |
| THD, at 1 kHz, MBW = 80 kHz | |
| MIC input to Master A L/R outputs, +16 dBu, typical | < 0.005% |
| Frequency Response, -3 dB, ref. 1 kHz, any input to any Mixer output | 15 Hz to 70 kHz |
| Crosstalk, 1 kHz | |
| Fader & FX/AUX/MON-Send attenuation | > 85 dB |
| Channel to Channel | < -80 dB |
| CMRR, MIC input, 1 kHz | > 80 dB |
| Input Sensitivity, all level controls in max. position MIC / LINE (Mono) / LINE (Stereo) / CD (Stereo) | -74 dBu (155 µV) / -54 dBu (1.55 mV) / -34 dBu (15.5 mV) / -34 dBu (15.5 mV) |
| Maximum Level, mixing desk | |
| MIC inputs | +21 dBu |
| Mono Line inputs / Stereo Line inputs | +41 dBu / +30 dBu |
| All other inputs | +22 dBu |
| All other outputs | +22 dBu |
| Input Impedances | |
| MIC / Insert Return | 2 ㏀ / > 3.3 ㏀ |
| 2Track Return & CD In | 10 ㏀ |
| All other inputs | > 15 ㏀ |
| Output Impedances | |
| Phones | 47 Ω |
| All other outputs | 75 Ω |
| Equivalent Input Noise, MIC input, A-weighted, 150 ohms | -130 dBu |
| Noise, Channel inputs to Master A L/R outputs, A-weighted | |
| Master fader down | -97 dBu |
| Master fader 0 dB, Channel fader down | -87 dBu |
| Master fader 0 dB, Channel fader 0 dB, Channel gain unity | -81 dBu |
| Equalization | |
| LO Shelving | ±15 dB / 60 Hz |
| MID Peaking, mono inputs | ±15 dB / 100 Hz to 8 kHz |
| MID Peaking, stereo inputs | ±12 dB / 2.4 kHz |
| HI Shelving | ±15 dB / 12 kHz |
| Master EQ 11-band (63, 125, 250, 400, 630, 1k, 1.6k, 2.5k, 4k, 6.3k, 12kHz) | ±10 dB / Q = 1.5 to 2.5 |
| Power Consumption | |
| without lamp / with lamp | 55 W / 60 W |
| Filter | |
| LO-CUT, mono inputs | f = 80 Hz, 18 dB/oct. |
| VOICE FILTER, mono inputs | switchable |
| FEEDBACK FILTER, MON 1/2 | 70 Hz to 7 kHz, Notch, -9 dB |
| Effects | |
| Type, effects presets | Dual stereo 24/48-bit multi effects processors, 100 Factory + 20 User, Tap-Delay |
| Remote control | Footswitch, MIDI |
| Display | 128 x 64 pixels, OLED |
| Digital Audio Interface | |
| Channels | 4 In / 4 Out |
| AD/DA Conversion, Sampling Rate | 24-bit, 44.1 / 48 / 88.2 / 96 kHz |
| PC Interface | USB2.0, Female Type B |
| Supported OS | See documentation |
| MIDI Interface | 5-pin DIN connector, In / Out |
| Protection | |
| Mixer Outputs (Relay controlled) | MON 1, MON 2, MASTER A |
| Switching Mode Power Supply (µC controlled) | Mains Over/Undervoltage, High Temperature |
| Phantom Power, switchable in groups | 48 V DC |
| Power Requirements (SMPS with auto range mains input) | 100 V to 240 V AC, 50 Hz to 60 Hz |
| Dimensions (W x H x D, without lid), mm | 818.5 x 155.0 x 498.5 |
| Weight, without lid | 14.5 kg |
| Optional Accessories | |
| Dust Cover for CMS 2200 | DC-SH2200-3 |
| Gooseneck Lamp, 12V/5W, 12”, XLR 4 pol. | DC-LITLITE-4P |
| FS 11 (Footswitch with LED) | DC-FS11 |
